2.4G Active Rfid Wristband Bracelet Watch W3310

Product Details

Product Details

Specially designed for active RFID people smart management system ,

applied for information management for special supervisor group,

like yong students, mental patient, mentally disabled people and prisoners in the prison, etc .

Its unique human engineering design make it more comfortable for carriers

Parameters

Name	2.45GHz RSSI UHF RFID active tag
Frequency	2.4GHz~2.48 GHz ISM
RF Power	-30.0dBm~7.0dBm
Reading distance	0~200m(depends on antenna)
Operating current	<20 mA, 3V
Modulation	GFSK
Communication rate	1M bps
ID No.	12 byte serial No.
Working temperature	-20℃~+45℃
Storage temperature	-30℃~+65℃
Life time	Read only: 3 years (1500ms transmitting interval&1dbm RF power)
RSSI function	YES
Battery	Lithium battery 500mAh
Electric hint	alarm when low battery
Material	ABS(ROHS), flame retardant
Environmental sealing	IP67
Drop test	1.2m
Weight	20g
Dimension	87mm56mm5mm

Excellent anti-collision mechanism makes multiple tags real time monitoring adaptable

High protection grade

Large user memory, which can be used for many flexible applications

Intelligent temperature monitoring function

Support RSSI function
