6dbi Passive uhf Rfid Circular Polarization High Gain Antenna A4006

收藏
Product Details

6dbi High Gain Antenna

The antennas can be connected with our serial UHF RFID readers, such as F5860, to realize the RFID function of data collection, which are widely used in various RFID systems.



Parameters

Technical Parameters



Name

A4206

Working frequency

840--960MHz

Gain

6dbi

Front-to-Rear Ratio

>18dB

polarization mode

circular polarization

Input Impedance(Ω)

50

VSWR

<1.3

power capacity(W)

100

Interface

SMA

Lightning protection

DC ground

Dimension

130*130*20

Weight

0.85kg

Radome Material

ABS/glass reinforced plastic

IP grade

IP65
