HID Emulation Keyboard Output Desktop Uhf Rfid Reader F5001E

收藏
Product Details

high performance Multiple Protocol UHF RFID Reader. It is designed upon fully self-intellectual property. Based on proprietary efficient digital signal processing algorithm, it supports fast tag read/write operation with high identification rate. It can be widely applied in many RFID application systems such as logistics, access control, attendance system, anti-counterfeit and industrial production process control system.


Application:


1. Vehicle management
2. Asset management
3. Personnel management
4. Production line management
5. Logistics and traceability management
6. Mine management
7. Ship management
8. Location management


Parameters

  •

  • NO.

    Name

    Parameters

    1

    Working   Voltage

    USB   5V

    2

    Working   Temperature

    -25～+65℃

    3

    Working   Humidity

    ≤95%（+25℃）

    4

    Storage   Temperature

    -40～+80℃

    5

    Tag   Protocol

    EPCglobal   UHF Class 1 Gen 2 / ISO 18000-6C

    6

    Working   Frequency

    840--960   MHz

    7

    Supporting Working

    Areas

    China   1, China 2

    US,   Canada and other regions following U.S. FCC

    Europe   and other regions following ETSI EN 302

    208   with & without LBT regulations

    Japan

    Korea

    Malaysia

    Taiwan

    8

    Output   Power

    Software   adjustable, step interval 1.0dB, maximum +25dBm

    9

    Output   Power Flatness

    ±0.2dBm

    10

    Receiving   Sensitivity

    -60dBm

    11

    RF Port Standing Wave

    ≤1.5

    12

    Reading   Range

    Maximum 0.5m (relate to tags type, transmitted power and application   environment)

    13

    Writing   Range

    Maximum 0.2m (relate to tags type, transmitted power and application   environment)

    14

    Interface   Communication Rate

    115200bps

    15

    Working Temprature

    Detection

    Support

    16

    RSSI

    Support

    17

    Antenna Type

    -1dBi ceramic antenna

    18

    Communication Port

    USB

    19

    Buzzer

    Yes

    20

    LED

    Red（power indicator）

    Green（status indicator）

    21

    Enclosure

    plastic case

    22

    Size

    130*82*11MM
