Contactless passive Desktop USB UHF RFID Reader Writer F5002

1

Working Voltage

DC +12V

2

Working Temperature

-25～+65℃

3

Working Humidity

≤95%（+25℃）

4

Storage Temperature

-40～+80℃

5

Tag Protocol

EPCglobal UHF Class 1 Gen 2 / ISO 18000-6C

6

Working Frequency

840--960 MHz

7

Supporting Working

Areas

China 1, China 2

US, Canada and other regions following U.S. FCC

Europe and other regions following ETSI EN 302

208 with & without LBT regulations

Japan

Korea

Malaysia

Taiwan

8

Output Power

Software adjustable, step interval 1.0dB, maximum +25dBm

9

Output Power Flatness

±0.2dBm

10

Receiving Sensitivity

-60dBm

11

RF Port Standing Wave

≤1.5

12

Reading Range

Maximum 0.5m (relate to tags type, transmitted power and application environment)

13

Writing Range

Maximum 0.2m (relate to tags type, transmitted power and application environment)

14

Interface Communication Rate

115200bps

15

Working Temprature

Detection

Support

16

RSSI

Support

17

Antenna Type

-1dBi ceramic antenna

18

Communication Port

USB

19

Buzzer

Yes

20

LED

Red（power indicator）

Green（status indicator）

21

Enclosure

plastic case

22

Size

12.0*12.0*3.0CM
